Adjusting side mirror angle/Global patented source technology
Opening&closing charge port door for electric vehicle
Adjusting HVAC(Heating,Ventilating,Air Conditioning)
Adjusting airvent operating direction
After receiving the signal, the central control system will send instruction to the door lock actuator
Adjust the opening and closing of the water valve actuator
Adjusting Headlamp Angle
Adjust the high beam and low beam for Headlamp
Regulates intake grille opening/closing positions
Adjust the high beam and low beam for Headlamp
ITEM | SPEC | |
Rated Voltage | 12V | |
Voltage Range | 9~16V | |
Operating Temperature Range | -40~120℃ | |
Storage Temperature Range | -40~130℃ | |
Operating Angle | 320° | |
Rated Torque(Nm) | 1.0 | |
Stall Torque(Nm) | Max 1.5 | |
Operating Speed(RPM) | Min 4 | |
Rated Current(mA) | Max 400 | |
Stall Current(mA) | Max 1600 | |
IP CLASS | IP67 | |
LIN Ver | LIN 2.2A | Only for LIN Type |
Baud rate | 19200 | |
Function | Self-learning function | |
* Customized design | ||
